The History of KQW /
(Click on photos to enlarge)
Herrold was born November 16, 1875, in the Mississippi River town of Fulton, Illinois. Herrold's father, Captain William Morris Herrold, was an inventor himself, and held patents on several agricultural devices. When young Charles was seven, Captain Herrold moved his family to Iowa. It was there, in the tiny community of Sloan, that Charles first began his education. He immediately showed an unusual scientific interest. The only science books in the entire village were two volumes of Zell's Encyclopedia, and Herrold read them from cover to cover several times. He quickly mastered all of his science and mathematical lessons, and, within a year of entering school, had built a perfectly-working telegraph line, including all of the instruments and batteries.
Enchanged with a visit they made to California, the family moved there permanently in 1888, and settled in San Jose. Once sufficient educational facilities were available to him, Herrold's education improved rapidly. He entered high school in 1891, and again quickly excelled. He constructed a telescope and a driving clock, and used it to take photographs of the sun using a high-speed focal plane shutter of his own construction. As a result of his experiments with this equipment, he fabricated a theory that sunspot distribances were directly connected in some way with electromagnetic phenomena, or radio. This of course has since become a basic principal of radio theory.
Herrold graduated from high school after three years. It was then he first heard of Marconi's experiments with wireless across the English Channel. This excited him greatly, and he read all the books he could find about the experiments of Hertz, Maxwell and others who had experimented in the areas of oscillating currents and electromagnetic waves. He experimented with wireless himself, and succeeded in transmitting a message sixty feet.
He entered Stanford University and began majoring in Astronomy, but later changed his major to Physics. One of his classmates at Stanford was later to become involved in radio licensing with the Federal Government, and would ultimately become President: Herbert Hoover.
Aside from a year's leave of absence because of poor health, Herrold spent four years at Stanford, and then went to work for an electrical firm in San Francisco. While there, he developed a deep sea diving illuminator and several mechanisms for the pipe organ. He continued his work there until 1906, when the San Francisco earthquake disrupted his work.
After the earthquake, he moved to Stockton, where he taught engineering at Heald's College, and shortly after became head of the Technical Department. He and his students constructed a high-speed turbine and generator, and laid foundations in such areas as underwater wireless, the firing of explosive mines by radio, and radio telephony. He left Heald's College and returned to San Jose in 1909, where he opened the Herrold College of Engineering and Wireless.
Herrold's school was located in the Garden City Bank Building, later known as the American Trust Building, at First and West San Fernando Streets. A school specializing in wireless needed an antenna, and the Herrold antenna attracted the attention of most passers-by. It was called a "carpet aeriel", and it stretched like an umbrella over the bank building and to three smaller buildings alongside it. Altogether, the antenna was constructed from over 11,500 feet of bronze wire!
One of Herrold's first and most active students was Ray Newby. He was interviewed in Stockton in 1959 by Professor Gordon Greb of San Jose State College, whose article about Herrold appeared in the "Journal of Broadcasting" in 1959. Newby was only sixteen when he and Herrold first transmitted voice from the school in 1909. He related the incident to Professor Greb:
Soon after Herrold's first voice transmission, experimenting began on a regular basis from the little spark transmitter. Newby related:
Once Herrold realized he had an audience of eager radio experimenters, he began to entertain them. He would discuss news items and read clippings from the newspaper, or play records from his phonograph. This got to be a more and more important part of the school's operations, and regular programs were heard from the station as early as 1910.
Herrold's wife Sybil later got into the act. Using many techniques of the modern disk jockey, she regularly aired what she called her "Little Ham Program". She later told Professor Greb that she would borrow records from a local music store, "just for the sake of advertising the records to these young operators with their little galena sets. And we would play up-to-date, young people's records. They would run down the next day to be sure to buy the one they heard on the radio the night before." And she encouraged regular listeners by running contests. "We would ask them to come in and sign their names, where they lived, and where they had their little receiving sets ... and we would give away a prize each week."
(This is the basis for KCBS' claim to be the nation's first broadcasting station. In order to be first, a station would have to be on the air earlier than any other, broadcasting on a regularly scheduled basis, and would have to be "broadcasting" in the truest sense of the word. Almost all radio communication up until then had been point-to-point transmissions, with a specific person designated as a receiver. Herrold and his wife and students were transmitting to whoever could receive them. In later years, Herrold himself would claim that he was the first person to use radio for the purpose of broadcasting.)
In time, Herrold tired of the raspy sound of his spark transmitter. He began experimenting with other methods of voice transmission, searching for a method that would be free of any spark noise. He experimented with many types of sparks and arcs, until he fell upon a new concept. Arc-type street lamps of the time had a curious habit of "singing" -- they would occasionally emit a humming sound, created by oscillations of the arc. Herrold reasoned that if he could raise the frequency of the oscillations above the range of hearing, then he could modulate it and use it as a carrier for higher-quality sound transmission.
Herrold and his students began experimenting on Herrold's "arc-phone". Newby recalled that, to raise the frequency of the arc, they had to enclose it in a tube insulated in alcohol (they later used distilled water). He said:
This was able to quench the arc, which would make it vibrate or oscillate at a higher frequency ... and that's exactly what (Herrold) was able to do.Herrold got around this problem by wiring four or five microphones together, and water-cooling them to hold the temperature down.
By 1912, Herrold had perfected and tested his arc-phone to the extent that it interested the National Wireless Telephone and Telegraph Company in his work. National was a manufacturer of arc-based telegraph transmitters, which it sold to the armed forces. He installed his arc-phone system for the U.S. Navy at Mare Island and Point Arguello. And on June 20, 1912, he installed an arc-phone in the Fairmont Hotel in San Francisco, and succeeded in contacting and talking with his San Jose station. With the stockholders of the company watching, and with two transmitters at each location to guard against breakdown, he set up communication with his student assistants in San Jose. This communication link was to continue on a regular basis for over eight months.
Herrold's student assistants included Newby, Kenneth Sanders, Frank Schmidt and Emile Portal. Many of his students went on to play important roles in the establishment of wireless in this country. Some of them went into radio work during the war. Portal later operated an early broadcast station.
Up until this time, there was very little government regulation of wireless. Licenses were not issued, and Herrold's station simply announced, "This is San Jose calling", or, "This is the wireless telephone of the Garden City Bank Building of San Jose." The Wireless Act of 1912 required licenses for the first time, and Herrold claimed his was the first to be issued for any voice transmission. He applied for his license December 4, 1912. The new regulations required some form of call letter identification for all stations, although the station could choose its own, and Herrold chose "FN", which was said to be backwards for "National Fone", referring to the National Wireless Telephone and Telegraph Company. Subsequent experimental call letters assigned to Herrold were 6XE (portable) and 6XF. The Fairmont Hotel station was 6XG. Other call letters used in later years were SJN.
Herrold's experimentation and expansion continued. He
set up a
listening room in the Wiley B. Allen Company, a San Jose music store,
to help encourage interest in radio. Some two dozen telephone earpieces
were connected to a receiver for the purpose of picking up Herrold's
broadcasts. In return, the company loaned records to Herrold for his
Herrold and his assistants conducted many tests of the station's signal strength. A Model "T" pickup truck fitted with a receiver was used to test reception at various remote locations. A receiver was placed in a shack in the Santa Cruz Mountains, and a 500-foot antenna strung between two mountain peaks. Reception reports were received from a number of distant points, never failing to amaze. Herrold received a letter in 1933 from Leslie F. Sherwood, who had sailed regularly in and out of San Francisco in the years between 1911 and 1913, and received both Herrold stations quite frequently. He wrote:
1914 was an eventful year from Herrold. He ended his association with N.W.T.& T. early in the year, but continued to experiment from his school. On February 13, he was able to communicate with his arc-phone station at Point Arguello. This was, at the same time, the longest distance that two voice transmitters had ever communicated. Herrold was granted a patent for his arc-phone May 12. That year, the "San Jose Mercury-Herald" announced to the public that, at a specific time, a large blue spark would jump from Herrold's Garden City antenna. It happened, exactly at the specified time. To this day, no one knows exactly how he did it.
About this time, Herrold's station attempted its first remote broadcast. The event was a play being performed in the auditorium at Normal College (now California State University at San Jose). The carbon button microphones Herrold used had very limited pick-up range, and his students improvised a reflector to collect the sound out of an old wooden chopping bowl. The signal was transmitted to the bank building through an ordinary telephone connection. Newby related,
By 1915, San Francisco had completely rebuilt herself from the ruins of the 1906 earthquake, and she wanted to show off her new look to the rest of the nation. To celebrate the opening of the Panama Canal, the Panama Pacific International Exposition was held in the city, and elaborate buildings were constructed on vast grounds in what is now the Marina District. The Liberal Arts Building of the fair was to include a radio exhibit, and Dr. Lee DeForest was asked to set up a display. In addition, Lt. Ellery Stone, who was San Francisco's government radio inspector, visited Herrold in his San Jose laboratory, and arranged for him to make regular broadcasts to be picked up by a receiver at the fair. Herrold agreed, and broadcast six to eight hours of music daily for the duration of the Exposition, where its visitors could listen through headsets. These broadcasts proved the reliability of Herrold's equipment. In addition, Dr. DeForest's transmitter at one point refused to operate properly, and so his receiver was also tuned to the Herrold station to demonstrate the DeForest equipment.
Herrold's broadcasting activities in San Jose continued until World War One. On July 31, 1918, however, all non-government radio stations were ordered shut down, to prevent any accidental dissemination of war information to foreign subversives. This ban was not lifted until the following year. During this time, Herrold continued the training of wireless operators at his school. When the ban was lifted, Herrold was back on the air with his arc-phone.
During the next two years, the station operated under a number of different licenses of different power and wavelength specifications. One was variable from 150 to 25,000 meters, and another was variable up to 1,000 watts in power.
Everything suddenly fell apart for Herrold in 1921. Broadcasting was now an activity being practiced by a number of radio stations around the country, including pioneer stations KDKA, WHA and WWJ. The government finally decided to regulate this new kind of radio transmission. It decreed that all stations were to have a new type of license, known as "limited commercial", and all stations were to share time on a single frequency, 360 meters. This announcement was fatal to Herrold and to his arc-phone. He explained in a letter, dated 1932:
During the KQW era of Herrold's school, the station would announce, "This is Herrold Laboratories, broadcasting over our 'bulb-phone'". Herrold referred to tubes as "bulbs", as it was natural for his arc-phone to become a "bulb-phone".
Another innovation of Herrold's during these years was used in the broadcasts of the Elks' Club Band, a regular program on KQW. Instead of using a single microphone to pick up the band, Herrold's crew attached a carbon button microphone to each instrument, anticipating today's recording methods by almost forty years.
About the same time, the Rev. Dr. William Keeny Tower, pastor of The First Baptist Church in San Jose, became interested in the idea of a radio station operated by the church. His plan was approved by the church board, and Dr. Towner contracted with Harry Saine, a personal friend and electrical engineer, to help obtain a license and build the station. But a radio license was not as easily obtained as had been hoped, as Saine later wrote to a friend:
We learned that Dr. Herrold had a license, but did not know that he wanted to dispose of it. We tried to contact Dr. Herrold but for some reason or another we were unable to do so for some three or four weeks. At last I got an audience with him, only to learn that he had given a thirty day option to another group only a few days before, and had turned over to them his old license. Things looked bad, for we knew that the government would not grant two licenses for this community. Dr. Herrold was very favorable to The First Baptist Church, but his hands were tied. The group who had obtained the option was a civic oranization, and did not desire to use the license themselves, but wanted to see that something substantial and definite was done to the end that San Jose would have a radio station of which it would be proud.
Doc Herrold stayed on with KQW as a technician for a few years, but soon dropped out of the operation entirely. He tried his hand at selling radio receivers for a while, and later hosted childrens' programs on KTAB and KFWM, both in Oakland. However, he never again regained a position of importance in broadcasting. Herrold, the man who watched the business of radio broadcasting grow up around him and leave him behind in the dust, died unrecognized in a Hayward rest home in 1948, at the age of 72.
Hart, who had been a farmer for many years, was now operating the station as a service to Central California farmers, apparently the first station in the area to whole-heartedly do so. "If you had a problem," he later recalled, "you wrote us and whatever it was, we'd get the answer for you .... " He was assisted in this endeavor by Stanford University, the University of California and the Agricultural Extension Service. In four years, KQW handled no less than 25,000 questions.
Cooperating with government agricultural agencies, KQW set up a system of nine shortwave radio transmitters that helped gather market news and price information. This, according to Hart, was "so the farmer could known the prices as soon as the buyer."
KQW was also the first area station to begin full-fledged efforts in advertising, and the station soon had a host of sponsors. They included the Union Oil Company, the Southern Pacific Railroad and the Sperry Flour Company. Hart's system of advertising was 25 years ahead of its time: instead of selling entire programs to sponsors, he sold them what are now called "spot announcements" -- short commercials read during the beginning, middle and end of each program. Hart said this insured the "political independence" of the station's programming. The only exception was Sperry Flour, which purchased an entire cooking show.
Another unique arrangement was the one made with Union Oil. That company paid the bill for telephone lines to a remote studio located in the Agriculture Building at the State Capitol in Sacramento. "Union Oil was our biggest advertiser," said Hart. "They paid us to maintain the lines to Sacramento, and all we had to do in exchange was announce each time we used them, 'These lines are maintained for the benefit of rural California by the Union Oil Company'."
On January 14, 1930, Hart was given an option to purchase the station from The First Baptist Church. A bill of sale was signed on March 31 of that year, with the license being transferred to the Pacific Agricultural Foundation, Ltd. The church was paid a specific sum of money, the payment of which was spread over a number of years. In addition, the church received the right to broadcast religious services up to five hours each Sunday without cost.
In1934, Hart sold KQW and the Pacific Agricultural Foundation to Ralph Bruton and Charles L. McCarthy. Brunton was one of the owners of KJBS in San Francisco, and McCarthy was the Manager of Station Relations for NBC in San Francisco. Hart continued to manage the station as President of the foundation, so that the station continued its service for many years afterward. KQW's studios were moved to the KJBS Building on Pine Street in San Francisco, where both stations operated under one roof for several years. An auxiliary studio continued to be maintained in San Jose. The power of the station was increased, first to 1,000 watts, and finally to 5,000 watts in 1935.
KQW became the San Jose affiliate of the new Mutual-Don Lee Network in 1937, but lost its network connection in 1941. Without quality network programs, it was unable to make a major impact in the local radio market.
But the fate of the station changed in 1942. That year, CBS offered to purchase KSFO, its San Francisco affiliate, but the offer was rejected by KSFO's owners. Immediately thereafter, CBS approached KQW with an offer of affiliation, which was accepted. KSFO had occupied a lavish studio complex in the Palace Hotel, which was owned by CBS. So, KSFO was evicted, and KQW moved in. Charles L. McCarthy was named the General Manager of KQW, and also became the regional Vice President for CBS.
After the affiliation with CBS, the KQW programming spotlight shifted from agricultural to network programs, although regular farm features continued to be an important aspect of the station's schedule. The auxiliary studios in San Jose were completely abandoned, and all operations shifted to the Palace Hotel. CBS wanted a San Francisco affiliate, but the city of license was still officially San Jose. As a result, an announcer was always on duty at the transmitter, whose sole duty was to make the station identification announcement between each program, just to keep everything legal in the eyes of the F. C. C. KQW continued to operate in this manner throughout the forties.
As America entered the Second World War, CBS quickly became a leader in war coverage, with some of the nation's brightest young radio journalists filing daily reports from the front. The voices of Edward R. Murrow, Walter Cronkite, John Daily and Eric Sevareid were heard daily with their reports from Europe.
San Francisco's location on the Pacific made it the logical choice for CBS to center its news-collecting efforts for the war in the Pacific. The network operated a large news-gathering complex in the KQW studios at the Palace Hotel. A crew of field reporters followed the troops in the Pacific with wire recorders and short wave transmitting equipment. Their reports were received at KQW and relayed Eastward to a waiting public. A regular CBS program called "Dateline San Francisco" was one of the more important news programs that originated from that city during the war. The entire KQW news staff joined forces to produce this program, a lively report on the feature side of the news in the war and the West.
After the war, KQW found itself in a competition with KSFO for the use of its frequency of 740 kcs., the last 50,000 watt frequency available in Northern California at that time. The competition was a long a protracted one.
In 1941, when KSFO was still the CBS affiliate in the area, the network had entered into an agreement with KQW which called for KSFO to take over KQW's frequency and increase its power to 50,000 watts. KQW, which was by then operating at 5,000 watts on the frequency, was to move to KSFO's dial position. The entire transaction was awaiting approval by the F. C. C. when a wartime freeze was placed on all station changes. By the end of the war, however, the CBS affiliation belonged to KQW, and CBS was not about to give up its plans for a 50,000 watt affiliate in the Bay Area. It filed a competing application for a power increase at 740.
After lengthy hearings, the F. C. C. granted the power increase to the original applicant, KSFO. However, the management of KSFO began to have doubts about the future of AM radio, and were putting all of their money into their new television station, KPIX. Negotiations were re-opened with CBS, and the result was that KSFO gave up its claim for the 740 dial position, in exchange for the CBS-TV network affiliation for San Francisco.
In 1949, CBS purchased the license of KQW outright, and changed the call letters to KCBS. An elaborate multi-tower antenna site was constructed at Novato in Marin County. The new high-power network-owned facility went on the air in 1951.
KCBS programming during the 1950's consisted of a mixture of network programs and disk jockey music programs. In the late fifties, KCBS developed a concept they called "Foreground Radio". Under the leadership of Jules Dundes and Maurie Webster, a sort of hybrid of personality, news, and the area's first telephone talk show was developed. Owen Spann ran the morning commuter's disk jockey program at the station, but several talk shows, particularly "Viewpoint" and "News Conference", were intregal parts of the KCBS format. This emphasis on information programming resulted in KCBS abandoning all music programs in 1968 and beginning round-the-clock all-news programming. KCBS became the first station in the Bay Area to successfully utilize this concept. KCBS continued its all news format with little competition for the next thirty years.
"A History of Santa Clara County", by Eugene T. Sawyer.
